BIESSE Akron 1440

BIESSE AKRON 1440-A Edge Banding Machine

Year of Manufacture: 2015

The BIESSE AKRON 1440-A is a fully automatic single-sided edge banding machine designed for precise gluing and finishing of flat panel edges using roll materials (melamine, PVC, ABS, veneer) and strip materials (solid wood, laminate, knife veneer, etc.).

It offers high performance, reliability, and excellent finishing quality.

Main Features

• NC control system with touchscreen

• Automatic start of processing units

• Direct selection for second pass processing

• Operating data acquisition

• Software-guided maintenance

• Suitable for roll and strip edge materials

Technical Specifications

• Workpiece thickness: 10 – 60 mm

• Thickness with MFU unit (profile-dependent): 10 – 35 / 60 mm

• Edge height: 14 – 64 mm

• Edge thickness (roll): 0.4 – 3 mm

• Edge thickness (strip): 0.4 – 10 (12) mm

• Workpiece overhang: 25 mm

• Minimum panel length: 140 mm

• Minimum width (140 mm length): 85 mm

• Minimum width (250 mm length): 50 mm

• Feed speed: 12 m/min

• Dust extraction connections: 8 x Ø100 mm

• Air pressure: 7 bar

• Glue pot capacity: approx. 2 kg
  (Depending on selected units)

Machine Units & Equipment

VC-511 Gluing Unit
Applies hot-melt adhesive, feeds the edge band, automatically cuts it from the roll and presses it onto the panel with perfect positioning.

IN-801 End Cutting Unit
Cuts front and rear edge overhangs with 0° to 15° inclination.

AR02 E – Twin-Motor Multifunctional Profiling Unit
For corner rounding and profiling of synthetic edges up to 3 mm thickness.

RT02 Jointing Unit
Prepares the workpiece edge before gluing.
Equipped with two 1.8 kW high-frequency motors at 12,000 rpm.

RB02 Scraping Unit
For finishing thick PVC/ABS edge bands.

RC02 Flat Scraper Unit
Removes excess glue at the panel-edge junction using pressure rollers and a flat blade with controlled engagement.

SZ02 Buffing Unit
Cleans and polishes the edge with cloth buffing wheels.
Automatically adapts to workpiece thickness.

ADZ02 Anti-Adhesive Spray System
Precise application of release agent via NC-controlled injectors.

PRO-GLUE Kit

• TEKNO-GLUE system

  • Controlled glue roller contact

  • Automatic retraction when feed stops

  • Automatic ON/OFF of the gluing unit

• REVERSE system

  • Forward and reverse rotation of the glue roller

Electrical and mechanical preparation for PUR glue systems on EVA-configured machines.

NC Axis Automatic Adjustment Systems

• NC axis for fine trimming unit

  • Automatic adjustment to edge type and thickness

  • Multi-profile cutter set:
    25° chamfer, R=2 mm, R=1 mm, straight profile for solid wood

• NC axis for profiling unit

  • Automatic sensor adjustment according to edge thickness

  • Corner-only machining function

• NC axis for scraping unit

  • Automatic adjustment of sensors and tools via control system
